| No. | Item | Unit | Data |
|---|---|---|---|
| 1 | Operating weight | kg | 9000 |
| 2 | Bucket capacity | m³ | 0.33 |
| 3 | Boom length | mm | 3722 |
| 4 | Arm length | mm | 1672 |
| 5 | Engine model | / | YAMMAR 4TNV98C (Intercooled Turbo) |
| No. | Item | Unit | Data |
|---|---|---|---|
| 6 | Cylinders | pcs | 4 |
| 7 | Rated Power | kW/r/min | 45 kW / 2100 |
| 8 | Engine Displacement | L | 3.054 |
| 9 | Travel speed | km/h | 2.6-4.4 |
| 10 | Swing speed | rpm | 11.6 |
| 11 | Grade Ability | ° (%) | 35 (70) |
| 12 | Tractive effort | kg/cm² | 0.58 |
| 13 | Bucket Digging Force | kN | 57 |
| 14 | Arm Digging Force | kN | 39 |
| 15 | Fuel tank capacity | L | 135 |
| 16 | Hydraulic oil tank capacity | L | 82 |
| 17 | Main pump type | — | Variable Displacement Piston Pump |
| No. | Item | Unit | Data |
|---|---|---|---|
| 18 | Maximum flow | L/min | 2.1×70.5 |
| 19 | Swing hydraulic motor type | — | Plunger Quantitative Motor |
| 20 | Travel hydraulic motor type | — | Plunger Quantitative Motor |
| 21 | Wheel-base | mm | 1850 |
| Symbol | Item | Unit | Data |
|---|---|---|---|
| A | Length of track | mm | 2752 |
| B | Ground clearance of platform | mm | 500 |
| C | Overall length | mm | 6146 |
| D | Transport height | mm | 2662 |
| E | Transport width | mm | 2242 |
| F | Tail Swing radius | mm | 1802 |
| G | Track gauge | mm | 135 |
| H | Max. lower width | mm | 2242 |
| I | Width of track shoe | mm | 450 |
| J | Min. ground clearance | mm | 367 |
| K | Height of track | mm | 260 |
| L | Max. width of upper structure | mm | 2242 |
| Symbol | Item | Unit | Data |
|---|---|---|---|
| a | Max. digging radius | mm | 6502 |
| b | Max. ground digging radius | mm | 6372 |
| c | Max. digging depth | mm | 4172 |
| d | Max. vertical digging height | mm | 3662 |
| e | Max. digging height | mm | 7272 |
| f | Max. dumping height | mm | 5257 |
| g | Min. Front Swing radius |
