| NO.< | Item< | Specification |
|---|---|---|
| 1 | Operating Weight | 6000 kg |
| 2 | Bucket Capacity | 0.6 m³ |
| 3 | Bucket Width | 600 mm |
| 4 | Boom Length | 3000 mm |
| 5 | Arm Length | 1600 mm |
| 6 | Travel Speed | 2.4/3.8 (Lower/Higher) Km/h |
| 7 | Grade Ability | 35 % |
| 8 | Ground Pressure | 36.4 Kpa |
| 9 | Bucket Digging Force | 3770 Kj |
| 10 | Arm Digging Force | 2840 Kj |
| 11 | Engine Brand & Model | Yanmar 4TN9V4L |
| 12 | Rated Power (kW/Kw/rpm) | 51/37.4/2200 |
| 13 | Displacement | 3.053 |
| 14 | Cylinders | 4 |
| 15 | Cooling Type | Water-cooling |
| 16 | Engine Oil Capacity | 12 L |
| 17 | Fuel Consumption | 2.5-3.0 L/h |
| 18 | Overall Length | 5850 mm |
| 19 | Overall Width | 1880 mm |
| 20 | Overall Height | 2575 mm |
| 21 | Superstructure Width | 1885 mm |
| 22 | Counterweight Ground Clearance | 680 mm |
| 23 | Total Track Length | 2540 mm |
| 24 | Track Shoe Width | 400 mm |
| 25 | Total Track Width | 1880 mm |
| 26 | Min. Front Swing Radius | 2250 mm |
| 27 | Dozer Blade Width | 1880 mm |
| 28 | Max. Digging Radius | 6150 mm |
| 29 | Max. Digging Depth | 3820 mm |
| 30 | Max. Digging Height | 5760 mm |
| 31 | Max. Dumping Height | 4030 mm |
| 32 | Dozer Blade (Width×Height) | 1880×320 mm |
