| Basic parameters of the whole machine | Total weight | 6600KG |
|---|---|---|
| Shipping length | 6346 mm | |
| Total height during transportation | 2800 mm | |
| Transport width | 2200 mm | |
| Tire center distance | 2400 mm | |
| Counterweight ground clearance | 1035 mm | |
| Number of tires | 8×750-16 | |
| Boom length | 3560 mm | |
| Stick length | 1900 mm | |
| Working Range | Max. Digging Height | 6550 mm |
| Max. Dumping Height | 5100 mm | |
| Max. Digging Depth | 3380 mm | |
| Max. Digging Radius | 6590 mm | |
| Max. lifting height of earth shovel | 300 mm | |
| Max. digging depth of dozer | 100 mm | |
| Dynamical System | Engine Model | Yang Dong |
| Power | 60/55 KW | |
| Cooling method | Water-cooling Turbo | |
| Hydraulic System | Operating Pressure | 22 MPa |
| Main pump | SGP1A2XFZH9 (Shimazduo) | |
| Hydraulic valve | Korea | |
| Shape | Load Sensing System | |
| Performance Parameter | (SAE) Bucket Capacity | 0.36 m³ |
| Climbing ability | 30° | |
| Maximum digging force | 8200 N | |
| Travel speed | 35 KM/h | |
| Unit swing speed | 9–11 r/min | |
| Hydraulic oil capacity | — |
