| Item | Specification |
|---|---|
| Working weight (KG) | 8200 |
| Engine rated power (kw) | 70 |
| Bucket Capacity (m³) | 1.0 |
| Backhoe Capacity (m³) | 0.3 |
| Engine brand | Weichai |
| Engine model | WP4G95E 241 |
| Item | Specification |
|---|---|
| Rated Speed (r/min) | 2200 |
| Min.Fuel Consumption (g/(kW·h)) | 230 |
| Max.Torque (N·m/rpm) | 380/1400-1600 |
| Displacement (L) | 4.5 |
| Steering Angle | ±36° |
| Pressure of the system (Mpa) | 14 |
| Item | Specification (mm) |
|---|---|
| Total length | 6050 |
| Overall width | 2465 |
| Overall height | 3100 |
| Bucket Dumping Height | 2780 |
| Bucket Dumping Distance | 880 |
| Digging Depth | 52 |
| Max.Digging Depth | 4085 |
| Item | Specification |
|---|---|
| Min.Ground Clearance (mm) | 300 |
| Breaking Force (KN) | 47 |
| Loading Lifting Capacity (KG) | 2500 |
| Swing Angle of Excavator Grab | 180° |
| Max.Pulling Force (KN) | 60 |
| Digging Power of Excavator Grab (KN) | 50 |
| Digging Power of Dipper (KN) | 31 |
