| Item | Specification |
|---|---|
| Working weight (KG) | 9700 |
| Engine rated power (kw) | 92 |
| Bucket Capacity (m³) | 1.7 |
| Rated load of bucket (kg) | 3000 |
| Engine brand | Deutz with AC |
| Engine model | WP6G125 E22 |
| Item | Specification |
|---|---|
| Maximum engine torque (N·m) | 515 |
| Engine fuel tank capacity (L) | 137 |
| Maximum digging force (kN) | 127 |
| Hydraulic tank capacity (L) | 90 |
| Hydraulic system working pressure (MPa) | 16.5 |
| Item | Specification (mm) |
|---|---|
| Total length | 6890 |
| Overall width | 2440 |
| Overall height | 3080 |
| Maximum unloading height | 2993 |
| Unloading distance at maximum height | 1007 |
| Wheelbase | 2630 |
| Maximum traction (kN) | 97 |
| Item | Specification |
|---|---|
| Minimum turning radius on the outer side of the tire (mm) | 5097 |
| Minimum turning radius the outside of the bucket (mm) | 5901 |
| Climbing ability | 48% |
| Boost time (s) | 4.83 |
| Unloading time (s) | 1.07 |
| Descent time (s) | 3.25 |
| Three items and time (s) | 9.15 |
