Equipped with Cummins 4BT3.9-C100 engine, featuring high power, low noise, energy efficiency and low fuel consumption.
4F+2R fixed-shaft mechanical gearbox, suitable for various working environments.
Adopts semi-rigid suspension for the entire vehicle's walking structure.
Advanced operation control system with full hydraulic power steering, ensuring flexible and labor-saving operation.
Driver cab welded with section steel, providing high strength, impact resistance and reliable safety protection.
Suitable for construction in narrow spaces, with flexible operation and high work efficiency.
Standard heating and ventilation equipment; air conditioner is optional.
Humanized design for all maintenance points, improving the convenience of repair and maintenance.
The whole machine has excellent fuel economy and high reliability, making it an ideal equipment for engineering construction.
<
| Parameter Category< | Parameter Name< | Unit< | Value |
|---|---|---|---|
| Basic Parameters | Model | - | SD-08 |
| Total weight | kg | 7500 | |
| Engine Parameters | Engine model | - | Cummins 4BT3.9-C100 |
| Engine rated power/speed | kw/r/min | 70/2200 | |
| Engine fuel consumption | g/kw.h | ≤242 | |
| Engine maximum torque | N.m | 345 | |
| Transmission & Travel Parameters | Forward 1-4 gear speed | km/h | 2.4～10.4 |
| Reverse 1-2 gear speed | km/h | 4.9～8.9 | |
| Track board width | mm | 400 | |
| Dimension & Shovel Parameters | Ground pressure | kPa | 42 |
| Overall dimension (L×W×H) | mm | 4020×2450×2800 | |
| Bulldozer shovel (W×H) | mm | 2450×950 | |
| Blade maximum lifting height | mm | 736.5 | |
| Blade maximum digging depth | mm | 350 | |
| Adjustable cutting angle | ° | 55 | |
| Optional Equipment | Towing equipment/Scarifier | - | Fixed/Three Toothed |
<
| Equipment Category< | Specific Items |
|---|---|
| Standard Instruments | Voltmeter, Oil pressure gauge, Engine temperature indicator, Hydraulic oil gauge, Ampere meter, Hour meter, Engine oil pressure gauge |
| Functional Components | Towing & lifting attachment (see attachment for specific tools), Battery run-down protection, Hydraulic system shutdown |
| Cabin Equipment | Display monitor, Adjustable seat with safety seat belt, Cab light, Dashboard accessories |
The frame outside the bulldozer's cab is equipped with an anti-rollover function, but no corresponding certificate or certification is provided.
Our products will be continuously improved with technological advancement. Please confirm the differences between the parameters, structural features listed in this document and the actual product when placing an order.
