| Item | Specification |
|---|---|
| Working weight (KG) | 24660 |
| Engine power (kw/rpm) | 175/1800 |
| Blade capacity (m³) | Straight 7.8; U-type 8.4 |
| Engine Model | Cummins NT855-C280; QSNT-C240 |
| Item | Specification |
|---|---|
| Climbing performance (°) | 30 |
| Type of scarifier | Single-tooth; Three-tooth |
| Loosening depth (mm) | Single-tooth: 693; Three-tooth: 666 |
| Lifting height of scarifier (mm) | Single-tooth: 515; Three-tooth: 555 |
| Item | Specification (mm) |
|---|---|
| Overall length | 5528 |
| Overall width | 3725 |
| Transport height | 3527 |
| Number of track shoes (per side) | 39 |
| Track shoe width | 560 |
| Track center distance | 2000 |
| Item | Specification |
|---|---|
| Blade lifting height (mm) | 1210 |
| Blade depth (mm) | 540 |
| Forward speed of each gear (km/h) | F1: 0~3.8 F2: 0~6.8 F3: 0~11.8 |
