| Item | Specification |
|---|---|
| Total weight (kg) | 10400 |
| Engine rated power/Speed (kW/r/min) | 81/2300 |
| Fuel consumption of the engine (g/(kW·h)) | ≤220 |
| Engine max torque (N·m) | 414 |
| Item | Specification (mm) |
|---|---|
| Overall length | 4190 |
| Overall width | 2935 |
| Overall height | 3020 |
| Bulldozer shovel width | 2935 |
| Bulldozer shovel height | 960 |
| Caterpillar track board width | 450 |
| Item | Specification |
|---|---|
| Forward 1-4 gear (km/h) | 2.6~10.4 |
| Reverse 1-2 gear (km/h) | 3.7~6.7 |
| Land pressure (kPa) | 54.4 |
| Item | Specification |
|---|---|
| Blade max lifting height (mm) | 830 |
| Blade max digging depth (mm) | 350 |
| Towing equipment/Ripper (optional) | Fixed/three-toothed |
